Yuneec H520E-RTK

Centimeter-level accuracy thanks to Real Time Kinematics

Our commercial Hexacopter H520E receives one of the fastest and most reliable RTK systems in the world. Fully integrated into the H520E, it ensures the highest precision and the fastest possible operational readiness even under difficult GPS conditions like in cities, canyons, or forests. Thanks to Real-Time Kinematics technology, the new H520E RTK will be able to stand in the air with centimeter accuracy, enabling extremely precise photos, faster 3D mapping, and more accurate inspection flights.

The system works with 2 components, an RTK module on board of the H520E and a base station. In less than 30 seconds it can reach a centimeter-level accuracy, also under challenging GPS conditions (with respect to the base station). For an absolute global centimeter-level accuracy and in case you don't want to use a base station, the system can also be operated with a network RTK reference station (Network RTK through third-party provider, needs an internet connection, additional fees may apply).

KEY FEATURES

• RTK (Real Time Kinematic) module for high accuracy relative positioning: 1 cm + ppm horizontal / 2 cm + ppm vertical
• Keep cm precision in even GNSS challenging environment
• Built for faster and more precise mapping (e.g. complex surveying, inspections, mapping, 3D displays)
• 5 Hz update rate of position, velocity and time
• All data including raw GNSS data and real-time solution can be logged on board - ready for PPK (Post Processed Kinematics)
• Support signals of up to 3 GNSS constellations among GPS, GLONASS, Galileo and BeiDou
• Compatible with all existing Yuneec H520E camera payloads

Box Content:

• H520E Hexacopter with RTK module
• 2 Batteries 4S-6200mAh
• EU Charger
• 12v Charging lead
• ST16E Transmitter (Touchscreen)
• 1 ST16E battery
• USB charging cable
• Sun Shade Screen cover
• Neck strap
• SD Card
• User Manual

Recommended camera:

• E90x
